NA-860AC Hard Fabric Automatic Spreading Machine

NA-860AC Hard Fabric Automatic Spreading Machine

Specialized for sheets, car seat, sofa, synthetic Leather, thick denim, special material.

Make your spreading easier and more efficient:
• One-man operation
• Dual material feeding system
• Automatic edge alignment
• Adjustable tension controller
• Stable Loading

(1)Specialized for sheets, car seat, sofa, industrial, reprocessed, and special material. (Roll and fold)
(2)One-man operating which saves manpower and enhances working efficiency.
(3)Dual material feeding system which eliminates stretch of fabric.
(4)Automatic edge alignment saves huge wastage of fabric than manual spreading.
(5)Synchronized for fabric feeding and spreading with an adjustable tension controller.
(6)Static eliminator obviates the charges of nylon.
(7)Fabric bucket is located between front and back wheels which makes loading more stable.
(8)With encoder gear which makes moving position more accurate.

• Spreading speed: Max. approx. 97m/min.
• Spreading height: 20cm.
• Passage height: 23cm.
• Longitudinal edge accuracy: ±3mm.
• End edge accuracy: ±2mm.
• Diameter of cloth roll: 70cm.
• Weight of cloth roll: 150kgs.

• Layers preset control.
• LCD touch panel.
• Type of spreading control.
• Auto edge alignment.
• Auto pitcher elevator.
• Catcher for dual way spreading.
• Auto cutting system
• Emergency stop device.
• Dual material feeding.
• Auto material feeding.
• Length memory device.
